Sol-Ark 12K-2P Hybrid Inverter—Resilient Partial-Home Backup for NEM 3.0 Homes

Upgrade any Sol-Ark inverter with a military-grade EMP shield that meets MIL-STD-461G, guarding your solar array, batteries, and critical loads against electromagnetic pulses, solar flares, and severe lightning surges—so your power stays online when the grid and other systems fail.

Bring grid-independent peace of mind to your home with the Sol-Ark 12K-2P. This battery-agnostic, 48 V hybrid inverter delivers 12 kW of continuous, split-phase power to your essentials while accepting up to 13 kW of rooftop solar. A factory-installed transfer switch and 50 A grid pass-through eliminate costly service-panel upgrades, making installation fast and affordable.

Key Performance Highlights

• Partial-Home Backup: 9 kW automatic UPS keeps refrigerators, lighting, pumps, Wi-Fi, and home office gear running during outages.

• Built-In Transfer Switch (5 ms): Sub-UPS-class switchover protects sensitive electronics; no external ATS required.

• Battery-Agnostic 48 V Port: Works seamlessly with any LiFePO₄, AGM, or lead-acid bank; 185 A charger refills batteries quickly after a storm.

• NEM 3.0 & TOU Ready: Programmable, multi-season time-of-use settings store solar when rates peak and export excess when utility credits are highest.

• Dual MPPT & AC-Coupling: Two full-sized MPPT trackers plus 9 kW AC-coupled input let you mix string inverters or microinverters for maximum harvest.

• EMP-Hardened Option: Add MIL-SPEC shielding and dual surge suppression to stay online through lightning strikes and electromagnetic events.

• EV & Generator Integration: Two-wire start for gas/LP gensets and single-circuit smart-load shedding keep Level-2 chargers from draining your battery bank.

• Virtual Power Plant Ready: Revenue-grade metering and open communications prepare your system for future VPP and demand-response programs.

• Outdoor-Rated Durability: NEMA 4X aluminum enclosure, -40 °C to +50 °C operating range, 10-year extendable warranty.

Core Specs at a Glance

• Solar Input: up to 12 kW (13 kW STC), 150–425 V MPPT range, 500 V max

• AC Output: 9 kW continuous / 18 kW surge, 120/240 V split-phase (208 V compatible)

• Battery Charger: 185 A @ 48 V

• Grid Pass-Through: 50 A service-side or load-side connection

• Certifications: UL 1741-SB, IEEE 1547-2018; UL 9540 system options available

• Dimensions / Weight: 31.5 × 18 × 8 in; 78 lb

Power your essentials, slash peak-hour bills, and charge your EV—all with one smart inverter. Add the Sol-Ark 12K-2P to your cart today or reach out to our NABCEP-certified team for a free partial-backup design and quote.

Installation and User Manual: Download

Sol-Ark Low Voltage Battery Integration Guide: Download

Sol-Ark Residential Inverter Basic Programming Guide: Download

SDM630MCT RGM User Manual: Download

Spec Sheet: Download

UL Certificate 1741SB: Download
