Grundfos 22SQ15-220 Well Pump | 22 GPM | 1.5 HP | 220 Ft | 240 VAC (SC)
- Regular price
- $1,399.00
- Sale price
- $1,399.00
- Regular price
-
$1,635.50
Grundfos 22SQ15-220 Well Pump | 22 GPM | 1.5 HP | 220 Ft | 240 VAC
Grundfos 22SQ15-220 - SQ Series 3" Submersible Well Pump (2W - 200-240V)
- Ideal for use with 3" I.D. or larger boreholes
Rated 15 GPM @ 250' Head Lift
- Please see documents for sizing / pump curve information
1-1/2 HP Permanent-Magnet (PM) Stainless Steel Motor (2-Wire - 200-240V)
- Highly-efficient design with thermal overload protection for added safety
- Fitted with a replaceable cable plug for ease of use
Soft Start Design
- Allows for a low starting current with a smooth and steady acceleration
- Low current draw helps reduce wear & provides ability to use smaller gauge wire
Dry-Running Protection
- Helps extend pump life by preventing pump damage due to lack of water in well
Highly-Efficient Stainless Steel Pump
- Polyamide reinforced hydraulic pump components for more efficient energy use
"Floating" Impellers w/ Tungsten Carbine/Ceramic Bearings
- Allows for high wear resistance to sand which extends pump life
Top-Bearing Upthrust Protection
- Provides added protection to motor/pump during start-up
Overvoltage & Undervoltage Protection
- Prevents damage to the motor if voltage moves outside rated range
Overload Protection
- Reduces Motor RPM or turns off power to motor to prevent damage to motor
Overtemperature Protection
- Built-in temperature sensor ensures optimum operating conditions for the motor
2-Year Warranty
Product Specifications
Grundfos 22SQ15-220 Well Pump | 22 GPM | 1.5 HP | 220 Ft | 240 VAC Product Specifications
Product Manual
GRUNDFOS SMARTFLO (Product brochure)
GRUNDFOS SQE (Product brochure)
GRUNDFOS SQ, Submersible Pumps (Product brochure)
GRUNDFOS SQ (Product brochure/Pocket Guide)
DCW Quick Selection guide for Pressure Boosting (Product brochure)
SQ, SQE (Installation and operating instructions)
SQ, SQE (I & O instructions)
SQ, SQE, CU 331, and SP (Data booklet)
Product Warranty
Grundfos 2023 Limited Consumer Warranty
