ECO-WORTHY 5000W Solar Off-Grid Inverter Charger – 48V DC to 120V AC Split-Phase | Pure Sine Wave | 10,000W Peak (SC)

Eco-Worthy 5000W Solar Off-Grid Inverter Charger – 48V DC to 120V AC Split-Phase | Pure Sine Wave | 10,000W Peak

Power your off-grid home, cabin, RV, or backup system with the 5000W Solar Off-Grid Inverter Charger, engineered for high efficiency, stable performance, and seamless solar integration. This advanced all-in-one unit delivers pure sine wave output, 48V battery support, and 120V AC split-phase power, making it ideal for household appliances, tools, and sensitive electronics.

With 10,000W peak power, intelligent auto-detect frequency (50/60Hz), and a highly efficient >95% inverter design, this system provides dependable power even during demanding loads. The built-in MPPT solar charger handles up to 5000W of PV input, 500V open-circuit voltage, and 80A solar charging, ensuring fast, optimized energy harvesting.

Perfect for off-grid solar systems, hybrid setups, and emergency backup power, this inverter charger integrates AC charging, solar charging, and inverter mode in one powerful, reliable solution.

⭐ Key Features

AC Input Mode

• Rated Voltage: 110/120VAC

• Input Range: 90–140VAC

• Frequency: 50/60Hz (auto-detect)

• Efficiency: >95%

• Max Bypass Overload Current: 40A

• Overload/Short Circuit Protection: Circuit breaker

• AC Reverse Protection: Yes

Inverter Mode

• Pure Sine Wave Output – Safe for sensitive electronics

• Rated Power: 5000W

• Peak Power: 10,000W

• Output Voltage: 120VAC split-phase

• Rated Battery Input: 48V

• Minimum Start Voltage: 44V

• Power Saving Mode: Activates when load ≤ 25W

• Bypass Breaker: 63A

AC Charging Mode

• Compatible Batteries: Lead acid & Lithium

• Max Charge Current: 60A

• Charge Voltage Range: 40–60VDC

• Overcharge Protection: Alarm + automatic stop

PV (Solar) Charging Mode

• Max PV Input Power: 5000W

• Adjustable Solar Charge Current: 0–80A

• Max PV Open Circuit Voltage: 500VDC

• MPPT Operating Range: 120–450VDC

• Battery Voltage Range: 40–60VDC

• Charging Short Circuit Protection: Blown fuse

This 5000W off-grid inverter charger is the ideal solution for solar power systems, off-grid homes, remote cabins, battery backup setups, and hybrid installations requiring high power, high efficiency, and dependable pure sine wave output.
